ALOCODRAND® Aluminium Composite Panel is compounded with top and bottom layers of aluminium sheet, non-toxic polyethylene core material. Both surfaces are coil coated with special baking varnish.  ALOCODRAND® Fire Retardant Mineral Core is compounded with top and bottom layers of Aluminium sheet, inorganic compound flame retardant and nanometer fire-resistant core material, both surface are coil coated with special baking varnish.


General Properties
Testing Item Standard Result
Unit weight ASTM D792 t3mm = 6.4 kg/m²
t4 = 5.5 kg/m²
Outdoor temperature resistance ASTM D1654 No abnomity
Thermal expansion ASTM D696 24 - 28
Thermal deformation temperature ASTM D648 115°C
Thermal conduction ASTM D976 0.012kcal/m.hr°C
Flexural rigidity ASTM D393 14.0x10
Impact resistance ASTM D732 1.65kgf
Adhesive strength ASTM D903 0.78kg/mm
Sound-insulating rate ASTM E413 25
Flexural Elasticity ASTM D790 4055kg/mm²
Shear resistance ASTM D732 2.6kgf/mm²
Minimum bending radius ASTM D790 45mm / 70mm
Fire propagation ASTM E84 Qualified
Smoke developed ASTM E84 < 45
Wind-pressure resistance ASTM E330 Passed
Properties against water ASTM E331 Passed
Properties against air ASTM E283 Passed

PVDF Coating Finish
Testing Item Standard Result
Finish coat thickness ISO 2360 (CNS 8046) 30 +- 5um
Gloss ASTM D532-89 80% +- 5%
Pencil hardness ASTM D3363-74 2H
Toughness ASTM D4145-83 2T no rift
Adhesive force ASTM D3359-87 100/100 no peel
Impact resistance ASTM D2794 No Crack
Abrasion resistance ASTM D968-81 50-80KTR No Crack
Mortar resistance ASTM 605.2-90 24Hrs pat test exceed
Humidity resistance ASTM D714-87,
D2247-87		 3000hr no blister
Boiling-water resistance ASTM D3359-B Passed
Salt-spray resistance ASTM D117-94 3000hr no blister
Acid resistance ASTM D1308-87, AAMA
605.2-91, TEST#7, 7.31		 No effect
Alkali resistance ASTM D1308-87 Passed
Solvent resistance ASTM D2248-73, ECCA T5 & NCA NO.11-18 Passed
Color retention ASTM D2244-87, (85) E < 5
Chalk resistance ASTM D4214-89 Max value : 8 unit
Gloss retention ASTM D2244-85 90%











ALOCODRAND® COMPOSITE advantages of :-
  • Weather Durability up to 15 Years
  • Lightweight & Rigid
  • Strength & Superior evenness
  • Flexibility and Versatility – Cutting / Punching / Bending / Curving / Contour Cutting / Screwing / Gluing / Welding / Drilling / Riveting
    Easy to fabricate & install
  • Long lasting with low and easy maintenance
  • Extra thermal insulation
  • Extra sounds insulation
  • Fire resistance
  • Environmentally friendly
  • Recyclable
  • Affordability – Competitive Price
